TRI CLAMP MESH SEAL 2 inch - 7 Mesh

Tri Clamp Mesh Seal - 2 inch.

Made from high quality 304 grade stainless size 7 mesh and PTFE teflon.  The bead on this has been designed to fit any standard 2 Inch (50mm) tri-clover fitting.

This mesh screen is compatible with all the other 2 Inch Tri-Clover equipment and fittings that we sell.

The screen has a mesh size of 7 which will block particles larger than 2.83mm or 2830 microns.

This slightly larger mesh size makes this screen ideal for use in a distillation basket.

This Stainless Mesh Screen has a PTFE (Teflon) seal integrated around the outside of it.  The hard PTFE compound is highly chemical and heat resistant.  This can be used as a standard seal or alternatively, it can be used as a filter screen preventing the flow of large particulates (>2.83mm) going through your tri-clover fittings.

This fitting is often used for distillation to retain packing media or used in pot distillation to retain botanicals in the vapour stream

• 2 inch (50mm)
• Tri Clamp Seal Material: Teflon
• Temperature Range: -5° C to +200° Celcius (-22F - 400F)
• Highly resistant to Vacuum, Most Acids / Chemicals, Halogenated Hydrocarbons, Di-Ester, Lubricants, Petroleum Oils / Fuels, Silicone Oils / Greases
• 7 mesh Stainless Steel Screen.

Stainless steel mesh number indicates the count of openings per linear inch, with higher numbers (e.g., 400 mesh) representing finer, smaller openings, and lower numbers (e.g., 10 mesh) indicating coarser, larger openings. A higher mesh number corresponds to finer filtration, while lower numbers are used for heavy-duty applications like screening.
