COOLING COIL - SHORT

Cooling Coil - Short

• 304 Stainless Steel, 7.62 meters (25 feet) long tube
• Short Cooling Coil fits up to 26 liters (7 Gallon) Fermentor
• Easy to install and sanitize bulkhead fittings
• 1/2" NPT Connections
• Includes two 3/8" 90 degree QuickConnector™ fittings!

Dimensions:

Height 241.3 mm (9.5 inches)

Width 224 mm (8.82 inches)

Cooling Coil Owners Manual - V1 ©Blichmann Engineering

Cleaning and Maintenance Drain the liquid from coil and rinse with water. Drain water from coil and let dry. Clean the outside of the coil with Powdered Brewery Wash and a brush. Sanitize before installing into fermentor.

Operation The Cooling Coil may be sanitized with StarSan® or other brewing sanitizer. This product is to be used as part of a complete cooling system. A temperature controller, a recirculation pump, and a glycol chiller are preferred for operation. A food safe liquid, such as an FDA grade glycol should be used to pump through the Cooling Coils. Alternatively an ice water bath may be used instead of a glycol chiller.

This coil is pressure capable up to 50 psi and may be used with commercial glycol shilling systems.

The cooling coils will work best when fully submerged. If only half of the coil is submerged, the cooling speed will likely be diminished by half.
