BLOW TIE SPUNDING VALVE KIT

BlowTie Spunding Valve Kit

• This kit has been designed for simplicity and ease of putting together.
• If you want to control the pressure retained in a pressure vessel that is releasing pressure then the BlowTie Diaphram Spunding Valve is the tool for the job.
• The adjustment knob on the top of the unit makes it easy to increase and decrease the set pressure.
• This BlowTie unit can be easily dissassembled for cleaning using a phillips head screw driver.

This Kit Includes;

1 x Blow Tie Spunding Valve

1 x duotight 8mm tee piece

1 x duotight FFL to 8mm fitting

1 x 8mm Push in 0-15psi Gauge

1 x Premium Ball Lock Disconnect (MFL) Grey/Gas

2 x NEW Black 8mm straight joiner piecesPressure Fermentations

With pressurised fermentation becoming ever more popular it has become increasingly important to have a method of regulating and controlling this residual pressure from the fermentation process.

The BlowTie has been designed specifically for this reason.

Pressure Transfers;

• When transferring from keg to keg, keg to bottle, or fermenter to keg it's often a good idea to have head pressure in the keg you are filling into especially if you are transferring a beverage that is carbonated.
• For this reason the BlowTie can consistently control this head pressure giving you more consistent results and without losing carbonation in the process.
• Traditional spunding valves that use a simple spring against a seal are flawed right from the beginning as the physical aspects of the design dictate that you will have a significant difference between the opening pressure and closing pressure during operation.
• Brewers have tolerated this imperfection for long enough and now you can control these pressures far more accurately.
• The BlowTie has been made completely differently taking advantage of a diaphragm to actuate the sealing mechanism that will release pressure from the pressure vessel with much more accurate control pressure.

Instructions;

• Use the yellow adjustment knob to control the pressure coming out of the pressure vessel.
• Clockwise is higher pressure and anticlockwise is lower pressure.
• It is recommend gassing a keg to a known pressure e.g. 15psi then attach your Blow Tie Kit to the keg and adjust to 10psi.

Specifications;

1. Made from food grade acetal

2. Stainless screws

3. 8mm (5/16") push on both sides

4. 0-15psi pressure rating
